PA12 CF15 Filament 250g

The material is highly abrasive. We recommend the use of hardened steel or ruby nozzles.
Availabe：

Material Properties：

Name：

Triangle Lab - PA12-CF15

FEATAND BENEFITS

Material composition：Nylon & 15%high-modulus

Water absorption:weak

Application sectors:automotive and engineering industries to develop advanced prototypes, drones and end products

Shrinkage:very low

Dimensional stability:strong

Contrast contrast before and after PA12 upgrade

Twice the tensile strength of PA12

More than twice as hard as PA12

Higher heat resistance (up to 150°C) compared to unmodified PA12

High chemical resistance

▉What's in the box:

PA12+CF15 The filament is about 250g ， total weight is 340g.

PA12+CF is made using a specialty Nylon 12 [PA12] and high-modulus carbon fiber. This material offers an excellent combination of performance and printability. PA12 absorbs much less moisture than PA6-based materials and has superior retention of mechanical properties after exposure to humid environments.

The PA12 + CF has the technical capabilities of PA12 and has been further enhanced by the addition of15% carbon fibres. Compared to unmodified nylon PA12, it is characterized by high heat resistance and lower shrinkage.

The addition of carbon fibres allows for weight reduction of the component while maintaining its high structural rigidity.

▉Photo display：

SDS Test Report

 ROSH Test Report

PA12 + CF offers a wide range of applications across the industry, including the automotive and engineering industries, to develop advanced prototypes, drones and end products that require increased durability while reducing weight.

Carbon Fiber PA12 is made using high-modulus carbon fiber and a specialty Nylon 12 (PA12) that we chose for it’s printability, thermal properties, and chemical resistance. PA12+CF is widely used in a variety of industries due to its excellent chemical resistance, low moisture absorption, and wide processing window. Our formulation ensures very low shrinkage in the printed part resulting in excellent dimensional stability, making our PA12+CF an excellent choice for tools, fixtures, and jigs.
